AmScope MU1400 14MP Digital Microscope Camera for Still and Video Images, 40x Magnification, 0.5x Reduction Lens, Eye Tube or C-Mount, USB 2.0 Output, Includes Software

The AmScope MU1400 14MP digital camera has a CMOS color sensor for displaying still microscopy images and streaming live videos to a computer or projector. The camera has 40x magnification and a 0.5x reduction lens that ensures that the display has a similar field of view as the microscope eyepiece. The camera can be mounted in a C-Mount, or 23mm, 30mm, or 30.5mm eye tube. The camera includes image capture and editing software that provides still image and live video capture and editing capability, including measurement functions. The software supports JPG, TIFF, GIF, PSD, WMF, and BMP file formats and is compatible with Windows XP, Vista, 7, and 8; Mac OS X; and Linux. Camera drivers are compatible with Windows XP, Vista, 7, and 8; Mac OS X; and Linux. The software includes Windows APIs for native C/C++, C#, DirectShow, Twain, and LabVIEW that enable custom application development. The camera has a USB 2.0 data port (cable included). Camera Specifications Resolution14MP (4096 x 3288 effective pixels)Image typeStill image and video display and captureCamera typeBrightfieldCamera sensor1/2.3" Aptina MT9F002 CMOS (color)Magnification40xReduction lens0.5xMounting size23mm, 30mm, 30.5mm, C-MountFrame rate27fps at 1024 x 822; 10fps at 2048x1644; 1.8fps at 4096x3288Computer connectionUSB 2.0 (backward compatible on PCs only)File formatsJPG, TIFF, GIF, PSD, WMF, BMPSoftware packageImage capture and editing for Windows XP, Vista, 7, and 8; Mac OS X; and LinuxCamera driver compatibilityWindows XP, Vista, 7, and 8; Mac OS X; and Linux
