DC Boost Converter, DC-DC Step Up Converter Board 10-32V to 12-60V Voltage Regulator Booster Module Adjustable Voltage Step Up Power Supply Module

Package list: 1 * Voltage Converter Current Adjustment: 1, Adjust the CV potentiometer, depending on the load requirements, adjust the output voltage to the appropriate value, example:4 series of battery to 55V, 10 series LED to 37V 2, The module output current value is set to minimum (rotate counterclockwise C C potentiometer till you hear small crack sound from the potentiometer) 3, Connect to ammeter, connected to the LED or battery, adjust the C C potentiometer to the required current. If used for charging, discharge battery before adjustment. Because the more battery power, the smaller charging current. Note that current of this module cannot be adjusted with short circuit. 4, Turn light current adjustment, used to indicate whether the battery is fully charged.Red light is on when charging, green light is on when fully charged. Connect a fully charged battery to output end, and adjust turn light potentiometer till green light is on.
